FEATURES

Pixel Pitch: 9mm

Physical Density: 12.346 (dots / m2)

Protection Level: IP65

Patented Rapid NTR-LoK ™ Compression Pins

Fixed Curve Rigging Options (-15 °, -7.5 °, 0 °, 7.5 °, 15 °)

Full Circle, Convex, Concave and Display Designs

Dot Correction Technology

Easy To Remove / Replace Power Supply Module

Transparent Ratio: 15% Dual Mode Shifter Built-In

Scanning Mode: 1/4

Horizontal and Vertical view angle: 140 °

Brightness: 5,000cd / m2

Gray Scale: 16bit

Refresh rate: 2,000Hz

SOURCE

LED Configuration: 1R1G1B

LED Type: SMD3535

Life Span: 100 000 Hour

RESOLUTION

Module: 32x32

Cabinet: 64x64

SIZE / WEIGHT

Module: 288x288mm

Cabinet: 576x576x118mm

Cabinet Weight: 23 lbs. (10.5kg)

ELECTRICAL / THERMAL

AC 110-220V 50 / 60Hz

200W Max Power Consumption

70W Average Power Consumption
