FEATURES

Cool White LED Spot Luminaire

Animation and Frost Effects

3-Rotating Prism Facet

Low Heat, Quiet Operation, Hibernation Mode

Flicker Free Operation For TV and Film

SOURCE

230W Cool White LED Engine

60,000 Hour LED Average Life

PHOTOMETRIC DATA

8,500K,> 79 CRI,> 7,200 Lumens

17,500 LUX FC 1.626 @ 8.2 '(2.5m) (16 ° Full ON)

5,373 LUX 499 FC @ 8.2 '(2.5m) (32 ° Full ON)

EFFECTS

Motorized 16 ° - 32 ° Zoom and Focus

Bi-Directional Variable Speed ​​Wheel Animation

3-Facet Rotating Prism and Prism Macros

Frost Filter Hybrid Wash Effect

Motorized Zoom, Iris and Focus

High Speed ​​Mechanical Shutter and Strobe

Variable Dimming Curves

COLOR

8 Dichroic Colors

GOBOS

7 Interchangeable-Rotating / Indexing Glass gobos

7 Static-Stamped Metal gobos

Size: 27mm OD / ID 22mm

CONTROL / CONNECTIONS

(3) DMX Channel Modes (18/20/27)

RDM (Remote Device Management)

6 Touch Button Control Panel

Full Color 180 ° Reversible LCD Display Menu

8/16 Bit Resolution Movement Adjustable

3pin & 5pin DMX In / Out

SIZE / WEIGHT

Length: 14.8 "(375mm)

Width: 15.1 "(384mm)

Vertical Height: 23.7 "(601mm)

Weight: 46 lbs. (20.8 kg)

ELECTRICAL / THERMAL

AC 100-240V - 50 / 60Hz

350W Max Power Consumption

-13 ° F to 113 ° F (-25 ° C to 45 ° C)
