FEATURES

540 ° / 630 ° Pan

265 ° Tilt

8/16 Bit Resolution Movement Adjustable

6 Zone Chase Effects

6 Touch Button Control Panel

Optional Snoot and Diffusion Filter Holder

Full Color 180 ° Reversible Menu Display

Microphone for Sound Activated Programs

Rechargeable Backup Battery for Menu Display

Stand Alone Operation with Master / Slave Function

Software upload via DMX Optional External Accessary

LAMP

12x 15W RGBW Quad Color OSRAM LEDs

50,000 Hour Average Life

Photometrics

Max 21,320 LUX @ 2.5M

7 ° to 14 ° Field Angle Range

EFFECTS

Dimming: 0% - 100%

6 Zone Chase Effects

High Speed Mechanical Shutter / Strobe 1-18 FPS

COLOR

RGBW Color Mixing

CONTROL / CONNECTIONS

3 DMX Channel Modes (15/17/37)

5pin DMX In / Out

PowerCon Power In

SIZE / WEIGHT

Length: 397mm

Width: 214mm

Vertical Height: 295mm

Weight: 9kg

ELECTRICAL / THERMAL

AC 100-240V - 50 / 60Hz

240W Max Power Consumption

-25 ° C to 45 ° C
