FEATURES

540 ° / 630 ° Pan

265 ° Tilt

8/16 Bit Resolution Movement Adjustable

6 Touch Button Control Panel

Full Color 180 ° Reversible Menu Display

Microphone for Sound Activated Programs

Rechargeable Backup Battery for Menu Display

Stand Alone Operation with Master / Slave Function

Optional Software Upload via External DMX Accessory

LAMP

Philips 189-Watt MSD PLATINUM 5R

7,950 Lumen, 8,000k,> 75 CRI, 3,000 Hour Average Life *

Photometrics

Max 56.230 LUX @ 15M 2.5 °

EFFECTS

Frost Filter

Two Direction Rainbow Effect

Mechanical Dimming: 0% - 100%

High Speed Mechanical Shutter / Strobe

8 Facet Rotating Prisms

COLOR

12 Including Static Dichroic Colors + White (Open)

GOBOS

1 Gobo Wheel With 8 Interchangeable Rotating Gobos + Open

Size: 14mm OD / ID 6mm

CONTROL / CONNECTIONS

3 DMX Channel Modes (11/13/16)

3pin & 5pin DMX In / Out

SIZE / WEIGHT

Length: 360mm

Width: 330mm

Vertical Height: 470mm

Weight: 14.5kg

ELECTRICAL / THERMAL

AC 100-240V - 50 / 60Hz

338W Max Power Consumption

-25 ° C to 45 ° C
