FEATURES

90W Cool White Solid State LED Spot Luminaire

19 ° Beam, 8 Dichroic Colors

7 Interchangeable Rotating-Glass gobos

3-Facet and Linear Rotating Prisms and Frost Filter

High Speed ​​Mechanical Shutter and Strobe

Motorized Iris and Focus and Variable Dimming Curves

Low Heat, Quiet Operation, Hibernation Mode

Flicker Free Operation For Broadcast TV and Film

SOURCE

Solid State 90W Cool White LED Engine

20,000 Hour LED Average Life *

PHOTOMETRIC DATA

7,250 LUX 674 FC @ 8.2 '(2.5m)

EFFECTS

3-Facet and Linear Rotating Prisms and Prism Macros

Frost Filter Hybrid Wash Effect

Motorized Iris and Focus

High Speed ​​Mechanical Shutter and Strobe

Variable Dimming Curves

COLOR

8 Dichroic Colors

GOBOS

7 Interchangeable-Rotating / Indexing Glass gobos

Size: 27mm OD / ID 22mm

CONTROL / CONNECTIONS

(3) DMX Channel Modes (14/16/20)

RDM (Remote Device Management)

6 Touch Button Control Panel

180 ° Reversible Full Color LCD Display Menu

8/16 Bit Resolution Movement Adjustable

3pin & 5pin DMX In / Out

PowerCon In

SIZE / WEIGHT

Length: 11.9 "(301mm)

Width: 9.6 "(243mm)

Vertical Height: 17.1 "(435mm)

Weight: 23.0 lbs. (10.4 kg)

ELECTRICAL / THERMAL

AC 100-240V - 50 / 60Hz

180W Max Power Consumption

* LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power / Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
