FEATURES

Unique 21 ° Beam Moving Head Effect Luminaire

New Advanced Optic Collimator Lens

(20) Pixel Controlled 15W RGBW 4-in-1 LED

Laser-Like homogenized 4th Color Changing Beams

Fast and Precise 16-Bit Continuous 360 ° Pan / Tilt Rotation

Strobe and Dimming Selectable Curve Effects

RDM, Klingner ™ and Art-Net (DMX over Ethernet)

Flicker Free Operation for Broadcast TV and FILM

SOURCE

(20) 15W RGBW 4-in-1 LED

100,000 Hour Average LED Life *

PHOTOMETRIC DATA

37.630 LUX FC 3.496 @ 3.3 '(1m)

17,700 1,644 LUX FC @ 6.6 '(2m)

11,240 1,044 LUX FC @ 9.8 '(3m)

7.571 LUX 703 HR @ 13.1 '(4m)

5,172 LUX 480 HR @ 16.4 '(5m)

EFFECTS

Individual Pixel Control

Strobe and Dimming Curves Selectable

COLOR

RGBW

CONTROL / CONNECTIONS

(3) DMX Channel Modes (17/19/95)

RDM (Remote Device Management)

6 Touch Button Control Panel

Full Color 180 ° Reversible LCD Display Menu

8/16 Bit Resolution Movement Adjustable

3pin / 5pin DMX In / Out

Ethernet RJ45 In / Out (KlingNET ™ / Art-NET)

PowerCon Power In / Out

SIZE / WEIGHT

Length: 18.9 "(480.7mm)

Width: 10.2 "(260mm)

Vertical Height: 21.3 "(541mm)

Weight: 44.0 lbs. (20 kg)

ELECTRICAL / THERMAL

AC 100-240V - 50 / 60Hz

280W Max Power Consumption

5F to 113 ° F (-15 ° C to 45 ° C)
