FEATURES
IP65-Rated
7° Beam, 14° Field Angle
Full RGBW Color Mixing
No Fans - Silent Operation
Flicker Free Operation for TV and Film
Direct DMX Auto Addressing Option
Art-NET (DMX Over Ethernet) Support
Klingnet™ Support
RDM - Remote Device Management

SOURCE
18W RGBW Quad LED
100,000 Average Hour LED Life

PHOTOMETRIC DATA
9,310 LUX @ 1m (7°)

COLOR
Full RGBW Color Mixing

CONTROL / CONNECTIONS
(4) DMX Channels
8pin Data/Power Combo IP Cables In/Out

SIZE / WEIGHT
Length: 3.8” (96mm)
Width: 2.9” (73mm)
Vertical Height: 2.9” (73mm)
Weight: 1.1 lbs. (0.5 kg)

ELECTRICAL / THERMAL
24VAC
18W Max Power Consumption
14°F to 113°F (-10°C to 45°C)
Multiple Unit Linkable (Max 15 units per ELAR Q1 PSU™)
