CARACTERÍSTICAS
41° Beam Angle - 66° Field Angle
Fully Blended Color Transformations
Adjustable Frequency Settings for Flicker FREE Operation for TV and Film
Convection Cooled / Silent Operation
Removable Pendant and Yoke Mounting Brackets
E-Fly™ Internal Extended Range Wireless DMX Transceiver

SOURCE
(36) 3W RGBW LEDs
100,000 Hour Average Life*

PHOTOMETRIC DATA
3,650 LUX 339 FC @3.3’ (1m)
1,020 LUX 95 FC @6.6’ (2m)
458 LUX 43 FC @9.8’ (3m)
255 LUX 24 FC @13.1’ (4m)
164 LUX 15 FC @16.4’ (5m)

EFFECTS
Strobe and Color Macros
Dimming : 0% - 100%
Selectable Dimming Curves

CONTROL / CONNECTIONS
11 DMX Channel Modes (1 / 3 / 4x2 / 5x2 / 6x2 / 7 / 8 / 10)
Frequencies (1200Hz, 2400Hz, 4800Hz, 9600Hz)
E-Fly™ Internal Extended Range Wireless DMX Transceiver
4 Button Control Panel and LCD Menu Display
5pin DMX In/Out
RDM (Remote Device Management)
powerCON Power In

SIZE / WEIGHT
Length: 14.7” (374 mm)
Width: 9.9” (252.5 mm)
Horizontal Height: 12.0” (308.8 mm)
Weight: 14.0 lbs. (6.4 kg)

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
110W Max Power Consumption
-14°F to 113°F (-10°C to 45°C)
