SPECIFICATIONS

- Woofer: 8 "AA PA850, Aluminiumbasket, 50mm voicecoil

- High Driver: 1 "compression driver with 44mm voicecoil mounted on a 90 ° x60 ° CD horn

- Power Handling:

  175W continuous

  350W program

  700W peak

- Recommended input power: 100-250W @ 8Ohm

- Sensitivity:

  3 dB SPL

  121dB Peak

- Freq. response: (-3dB) 88Hz - 20kHz

- Freq. range: (-10dB) 75Hz - 21kHz

- Nom. dispersion h v x: (-6 dB) 90 ° x60 °

- Impedance: 8Ohm

- X-Over: 2800 Hz 12dB / 18dB

- Finish: black structure paint

- Protective Grid: powder coated steel grill with acoustic foam

- Connector: 2x NL4 Speaker

- Handle: 1 handle on the top

- Monitor angle: 45 °

- Pole mount: integrated M8 Screws for rigging eyes in all corners

- Cabinet: plywood

- Dimensions (LxWxH): 250x436x230mm

- Weight: 10kg

FEATURE OVERVIEW:

- Perfect matched components and case details

- Passive full range system for medium size applications

- Multifunctional case design

- Quadratic horn (rotatable)

- 90 ° x 60 ° dispersion

- First class mechanical manufacture for day-to-day operations

- Equipped with optimized 8 "MF / LF driver

- Large optional accessory range

- Ideal for mobile and install applications
