Specifications

- Pixel Pitch: 6.0mm (0.25 ")

- LED Configuration: 3-in-1 SMD 2121 LCD

- Pixel Density: 96x96; 27,777 per square meter

- Size: 576 x 576 x 75mm

- Module Quantity: 4

- Weight: 8.15Kg MECHANICAL RATINGS:

- Surface Flatness: Gaps <0.5mm Optical RATINGS:

- Brightness: 1200 NITS

- View Angle: 140 ° Horizontal / Vertical 140 °

- Distance: 20ft (6m)

- Gray Scale / Color Display: 14bit

- Brightness Adjustment: 100 0 ~ 100% Levels

- Processing: 14bit POWER SUPPLY:

- Operation Power: 100 ~ 240V 50-60Hz

- Max Power Consumption: 200W / per panel.

- Ave. Power Consumption: 80W / per panel

- Connections Power / Data: Power-PowerCon In / Out; Date EtherCon In / Out CONTROL SYSTEM:

- Control Mode: Synchronous Display with Control PC by DVI

- Frame Update Frequency: 50-60Hz

- Scan Mode: 1/12 Duty

- Refresh Rate: 960Hz

- Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD SDI

- Control Distance: Ethernet Cable <100m or Fiber Optic> 120m

- Support VGA Mode: 1024 x 768, 1280 x 1024, 1600 x 1200, 1920 x 1280

- Brightness Correction: Pixel, Module, Cabinet ENVIRONMENTAL:

- Operating Temp / Humidity: Fahrenheit: -4 ° + 104 ° / Celsius: -20 ° + 40 ° / 10-90% (No Condensation)

- Operating Life / MTBF: 100,000 Hours / 5,000 Hours

- Protection Level: IP20 (Front and Back) -

- Out of Control Rate: <% 00:02

- Listings: CE, FCC Class A, RoHS, China RoHS
